10kVA Single Phase Step Down Transformer 230V Input Orange

Product Code: 10000/1PH

10kVA Single Phase Step Down Transformer 230V Input Orange
2-year guarantee Icon
10kVA Single Phase Step Down Transformer 230V Input Orange

10kVA Single Phase Step Down Transformer 230V Input Orange

Product Code: 10000/1PH

  • 'Suitable for power distribution on construction sites with On and Off' switching allowing to isolate the device from the mains when not in use. By doing so, it effectively reduces power consumption during standby.
  • Output voltage of 110V
  • Complete with 4 x 16A and 2 x 32A Socket outlets
  • Integrated Isolator significantly extends the longevity of the product, ensuring its durability and reliability.
  • 110V working indicator shows whether the transformer is in use or switched off, providing visual confirmation for end users.
  • Complete with MCB protected input and output
  • Designed with high quality metal casing and heavy duty stand
  • IP44 rating for protection from solid objects larger than 1mm and splashes of water from any direction
  • 2-year guarantee

Additional Information

Compliance
BS EN61558
Degree of protection (IP rating)
IP44
Depth
485mm
Height
410mm
Number of phases
1
Primary voltage 1
216 - 253V
Rated power
10000VA
Secondary voltage 1
103V
Secondary voltage 2
121V
Width
674mm

ITEM
LAST UPDATED

Brochure - Briticent Catalogue_MD41.pdf
13/08/2025
Product Data Sheet (PDF) - DS 0333 V1.0 - Briticent Site Transformers.pdf
13/08/2025
Product Instruction Sheet (PDF) - INS 0116 V1.1 - 10KVA 1 Phase Transfomer.pdf
13/08/2025
